Formatted (512 bytes/sector) 8TB
Heads 10
Discs 5
Bytes per logical sector 512
Bytes per physical sector 4096
Recording density, KBPI (Kb/in max) 2509
Track density, KTPI (ktracks/in, 0 skew) 371
Areal density, (Gb/in2, @ 0 skew mid-disk) 930
Spindle speed (RPM) 7200
Internal data transfer rate (Mb/s max) 2850
Sustained data transfer rate OD (MiB/s max) 200 (210 MB/s max)
I/O data-transfer rate (MB/s max) 600
- ATA data-transfer modes supported PIO modes 0–4
- Multiword DMA modes 0–2
- Ultra DMA modes 0–6
Cache buffer 256MB (262,144KB)
Weight: (maximum) 716g (1.579 lb)
Average latency 4.16ms
Power-on to ready (sec) (typ/max) 23/30
Standby to ready (sec) (typ/max) 23/30
Startup current (typical) 12V (peak) 1.8A
Voltage tolerance (including noise)
Non-Operating temperature –40° to 70°C (Ambient Temperature, see sections 2.6.1 and 2.11)
Operating temperature 5°C
Operating temperature 70°C
Temperature gradient (°C per hour max)
- 20°C (operating)
- 30°C (nonoperating)
Relative humidity
- 5% to 95% (operating)
- 5% to 95% (nonoperating)
Relative humidity gradient 30% per hour max
Altitude, operating
- –304.8 m to 3,048 m
- (–1000 ft to 10,000+ ft)
