| Standards and Protocols |
IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Basic Function |
Full Duplex Flow Control (IEEE 802.3x) |
| |
Extends fiber distance up to 0.5km using 50/125um fiber |
| Ports |
1 Gigabit SFP port |
| |
1 1000M RJ45 port (Auto MDI/MDIX) |
| Wave Length |
Depends on the used SFP module |
| Network Media 1000BASE-FX |
Multi-mode/Single-mode SFP module |
| Network Media 1000BASE-X |
Multi-mode/Single-mode SFP module |
| Network Media 1000BASE-T |
UTP category 5, 5e, 6 cable (maxium 100m) |
| |
EIA/TIA-568 100Ω STP (maximum 100m) |
| LED Indicators |
PWR, LINK, RX |
| Dimensions (W*D*H) |
3.7*2.9*1.1 in. (94.5*73.0*27.0 mm) |
| Power Supply |
External Power Adapter |
| Max Power Consumption |
3.95W |
| Safety & Emission |
FCC, CE |
| Environment |
Operating Temperature: 040 (32104) |
| |
Storage Temperature: -4070 (-40158) |
| |
Operating Humidity: 10%90% non-condensing |
| |
Storage Humidity: 5%90% non-condensing |
| |
|
