LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
|
| L3 cache varies with CPU |
|
Chipset
|
Intel ® B760 Express Chipset
|
|
Memoria
|
Support for DDR5 7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
|
| 2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) of system memory |
| Dual channel memory architecture |
| Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
| Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| Support for Extreme Memory Profile (XMP) memory modules |
|
Gráficos Integrados
|
Integrated Graphics Processor-Intel® HD Graphics support:
|
| - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz |
| - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz |
| - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
| Support for up to triple-display at the same time |
|
Audio
|
|
|
| High Definition Audio |
| 2/4/5.1/7.1-channel |
| Support for S/PDIF Out |
|
LAN
|
Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
|
|
BIOS
|
|
|
| Use of licensed AMI UEFI BIOS |
| PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
Características Únicas
|
Support for GIGABYTE Control Center (GCC)
|
| Support for Q-Flash |
|
Software Incluido
|
Norton® Internet Security (OEM version)
|
| LAN bandwidth management software |
|
Sistema Operativo
|
Support for Windows 11 64-bit
|
| Support for Windows 10 64-bit |
|
Diseño
|
Micro ATX Form Factor; 23.0cm x 21.5cm
|
